← Lighting · TOOY · Lei /· 564.71 Ceiling · 220/240V · / · According to bulb · C2 Matte Black / C42 / C70G · / · H 14 x Ø 16 · 1 x Gu10 max 4,5W· full product card

· 564.71 Ceiling · 220/240V · / · According to bulb · C2 Matte Black / C42 / C70G · / · H 14 x Ø 16 · 1 x Gu10 max 4,5W

TOOY · Lei · Studio10

Article: 564.71
Type: Ceiling
Designer: Studio10
Materials: metal, glass, aluminum

LIGHT SOURCE

recommended: · GU10 LED dimmable · Lei · Ø 3,5 x H 4,6 · 3W - 2700K 220 lm × 1LAMPLED-GU102700D15 €

SPARE PARTS

· Clear Glass · Lei · Ø 6 x H 12564.VETCL40 €

· Frost Glass · Lei · Ø 6 x H 12564.VETFR45 €

ACCESSORIES

· Track feeding · trimless/ surface · L 11,2 x W 1,8 x H 1,8564.A42 €

· Track feeding joint · trimless/ surface · L 10,5 x W 1,8 x H 1,8564.B27 €

· Surface track end cap · trimless/ surface · L 2,6 x H 2,1564.C16 €

· Surface track end cap hole · trimless/ surface · L 2,6 x H 2,1564.D20 €

· Driver 60W max 10 spot · remote · /564.driver6050 €

· Track power feed “I” · surface · L 7,9 x W 3,5x H 1,9564.E4 €

· 1 m, 230V, black surface track · surface, not dimmable · L 100 x W 3,5x H 1,9564.SUR230V10033 €

· 2 m, 230V, black surface track · surface, not dimmable · L 200 x W 7,3 x H 2,6564.SUR230V20057 €

· 1 m 48V black surface track · surface, DALI · L 100 x W 2,6 x H 2,1564.SUR48V10099 €

· 2 m 48V black surface track · surface, DALI · L 200 x W 2,6 x H 2,1564.SUR48V200176 €

· 1 m 48V black trimless track · trimless, DALI · L 100 x W 7,3 x H 2,6564.TRIM48V100130 €

· 2 m 48V black trimless track · trimless, DALI · L 200 x W 7,3 x H 2,6564.TRIM48V200240 €

TECHNICAL

Control: According to bulb
Dimmable: yes
Weight: 0,8 kg

QUANTITY

394 € / pcs · EUR excl. VAT

394 €

FACTORY NOTES · printed in the article’s own block

NOTE
110/120V version available on request at an additional cost. Max. bulb dimensions (excluded): Ø3.5 H 4.9
p. 66
NOTE
p.66 prints «Light source: GU10 bulb» and «max LED bulb: 1 x Gu10 max 4,5W» without saying whether the bulb is included
p. 66

DOCUMENTS

PDFTechnical sheetarrives with the factory’s document set

PDFAssembly / care instructionsarrives with the factory’s document set

PDFCertificatesarrives with the factory’s document set

SOURCES · every page this card was read from

PDF

TOOY — Global Pricelist 2025 · p. 66

the price was read here · the article is printed here · the picture came from here · the drawing came from here
